GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 5-6 - ARP (Rear Panel) 5-31
5-6-1 Input/Output Signals for peripheral
Table 5-3 Input and Output signals for peripherals
Signal Name
Description
Connection from/via/to
Ethernet
Standard TCP/IP Ethernet
Syscon -> ARP -> 7P LAN Connector
External VGA
VGA signal output for external VGA monitor
Syscon -> ARP -> LG Connector -> 15P DSUB
Connector
Foot Switch
Foot Switch is mechanical switch that
connect a signal to ground
Foot Switch connector -> ARP(USB HUB)
Composite out for DVD Recorder
Compositor video signal output for DVDR
Syscon -> ARP -> BNC Connector
Composite in for DVD Recorder
Compositor input from DVDR
BNC Connector -> ARP -> Syscon
S-VHS out for DVD Recorder
S-VHS output signal for DVDR Recording
Syscon -> ARP -> S-VHS Connector
S-VHS in for DVD Recorder
S-VHS input signal for DVDR playback
S-VHS Connector -> ARP -> Syscon
Audio out L/R for DVD Recorder
Stereo audio output for DVDR Recording
Syscon -> ARP -> RCA Jack
Audio In L/R for DVD Recorder
Stereo audio input from DVDR for DVDR
playback
RCA Jack -> ARP -> Syscon
USB Port for BW Printer
USB Port for BW Printer
Syscon -> Backplane -> USB Connector(dual
R_A type) -> Front/BW Printer
USB Port for ECG
USB Port for ECG
ARP(USB HUB) -> USB Connector(R_A type)
-> ECG
USB Port for 4D
USB Port for 4D
ARP(USB HUB) -> USB Connector(R_B type)
-> 4D
USB Port for Digital Color Printer
USB Port for Color Printer
ARP(USB HUB) -> USB Connector(S_A type) -
> Color Printer
USB Port for DMC
USB Port for DMC
ARP(USB HUB) -> USB Connector(S_A type) -
> DMC
USB Port for USB Device
USB Port for USB Device
ARP(USB HUB) -> USB Connector(S_A type) -
> USB Device
USB Port for Remote
USB Port for remote control of VCR/DVD
Recorder
ARP(USB HUB) -> USB Connector(S_A type) -
> VCR
To Next Page
