GE LOGIQ P5 Service Manual

GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 9-8 - POWER 9-15
Section 9-8 POWER (cont’d)
Item Part Name FRU Number Description Qty FRU R1.0.X R2.0.X R3.0.X~ R4.0.X~
600 ACPC Assy 5144559 1 1 Yes Yes Yes Yes
601
LOGIQ P5 Transbox Assy 110V 5144560 LOGIQ P5 ONLY 1 1 Yes Yes Yes Yes
LOGIQ P5 Transbox Assy 220V 5144562 LOGIQ P5 ONLY 1 1 Yes Yes Yes Yes
LOGIQ A5 Transbox Assy 110V 5177417 LOGIQ A5 ONLY 1 1 Yes Yes Yes Yes
LOGIQ A5 Transbox Assy 220V 5177276 LOGIQ A5 ONLY 1 1 Yes Yes Yes Yes
602
Fuse Set 110 5168996 1 1 Yes Yes Yes Yes
Fuse Set 220 5177924 1 1 Yes Yes Yes Yes
603
Power Cord for 110v 2389073 110v 1 1 Yes Yes Yes Yes
Power Cord for 220v 5308254 220v 1 1 Yes Yes Yes Yes
Power Cord for China 2389074 Only China 1 1 Yes Yes Yes Yes
Power Cord for Israel 5189985 1 1 Yes Yes Yes Yes
Power Cord for Argentina 5189874 1 1 Yes Yes Yes Yes
Power Code for Italy 5189619 1 1 Yes Yes Yes Yes
Power Cord for Denmark 5189461 1 1 Yes Yes Yes Yes
Power Cord for ANZ 5189439 1 1 Yes Yes Yes Yes
Power Cord for UK/HK 5189398 1 1 Yes Yes Yes Yes
Power Cord for Switzerland 5189311 1 1 Yes Yes Yes Yes
Power Cord for India 5189127 1 1 Yes Yes Yes Yes
Table 9-8 POWER BLOCK

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
