DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 8-2 - DISASSEMBLY/RE-ASSEMBLY 8-65
8-2-24 Neck Rear
8-2-24-1 Tools
• Common pilIips screwdrivers
8-2-24-2 Preparations
• Shut down the system and switch off the main breaker.
8-2-24-3 Removal procedure
1.) Remove 2 rubber caps (1-2).
2.) Unscrew 2 screws and remove the Neck Rear.
Figure 8-100 rubber cap of neck rear cover
Figure 8-101 Open neck rear cover
(2)
(1)
