GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
2-2 Section 2-2 - General Console Requirements
Section 2-2
General Console Requirements
2-2-1 Console Environmental Requirements
2-2-1-1 Cooling
The cooling requirement for the LOGIQ™ P5 is 2000 BTU/hr. This figure does not include cooling
needed for lights, people, or other equipment in the room. Each person in the room places an additional
300 BTU/hr. demand on the cooling system.
2-2-1-2 Lighting
Bright light is needed for system installation, updates and repairs. However, operator and patient
comfort may be optimized if the room light is subdued and indirect. Therefore a combination lighting
system (dim/bright) is recommended. Keep in mind that lighting controls and diameters can be a source
of EMI which could degrade image quality. These controls should be selected to minimize possible
interface.
Table 2-2 Environmental Requirements for LOGIQ™ P5 Scanners
Operational Storage Transport
Temperature
10 - 30
o
C
50 - 104
o
F
-10 - 60
o
C
14 - 140
o
F
-40 - 60
o
C
-40 - 140
o
F
Humidity
30 - 85%
non-condensing
30 - 90%
non-condensing
30 - 90%
non-condensing
Pressure
700 - 1060hPa 700 - 1060hPa 700 - 1060hPa
Table 2-3 Environmental Requirements for an Ultrasound Room
Item Values
Power Source
refer to Table 2-4 on page 2-3.
Current Rating
7.5A (100V-120V); 3.5A (220-240V)
Radiation Shielding
NONE REQUIRED for ULTRASOUND ENERGY
Temperature
20-26 DEG. C (68-79 DEG F) for PATIENT COMFORT
Humidity
50% to 70% for PATIENT COMFORT
Heat Dissipation
2000 BTU/Hr.
Floor Landing
Approximately 680 - 800 kg/m
2
without Accessories
Floor Condition
Gradient: WITHIN 5 degrees
Weight
75 kg (165lbs) without Accessories
