GE LOGIQ P5 Service Manual

GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
5-58 Section 5-12 - Machine RFS
5-12-2 Enabling MRFS (cont’d)
8.) check the checkbox next to the name to set to the default contact. Then Press “Set Default Machine
Contact” button,
9.) Now the MRFS is enabled.
10.)When system detects high temperature or abnormal voltage, the system will send the RFS to the
OLC automatically.
Figure 5-62 Set Default Machine Contact

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
