GE LOGIQ P5 Service Manual

GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
8-116 Section 8-2 - DISASSEMBLY/RE-ASSEMBLY
8-2-51-1 How to start serial no read/write program (cont’d)
5.) If the win XP screen appears, run the window explorer. Move the cursor to bottom of the screen. If
the task bas appear, click the explorer icon.
6.) Run the “asn.exe” by double click. This execution file is in “C:\Arirang\target\bin” directory
Figure 8-154 Windows Explorer
Figure 8-155 “asn.exe”

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
