Report Formats
Report Format Name Description One Page
or Multiple
Page Report
4 by 2.5s + 1 Rhythm
Ld
Shows two parts:
• The upper part shows four columns of three rows of
waveforms. Each column is 2.5 seconds wide and
printed at 25 mm/s.
• The lower part shows one row of 10 seconds of
one lead. The rhythm lead shown in the report is
configurable.
One page
report
4 by 2.5s + 3 Rhythm
Ld
Shows two parts:
• The upper part shows four columns of three rows of
waveforms. Each column is 2.5 seconds wide and
printed at 25 mm/s.
• The lower part shows three rows of 10 seconds of
three leads. The rhythm leads shown in the report are
configurable.
One page
report
4 by 10s Shows four columns of 3 rows of waveforms. Each column
is 10 seconds wide and printed at 25 mm/s. Three leads are
printed on each page. This results in a four page report.
Multiple
page report
Pharma If you purchase the PHAR - Pharmacy option, you can
select this type for the report.
Shows three parts:
• The upper part shows four columns of three rows of
waveforms. Each column is 2.5 seconds wide and
printed at 25 mm/s.
• The middle part shows two rows of 10 seconds of
three leads. The rhythm leads shown in the report are
configurable.
• The lower part of the report is text, such as the
measurements and patient information.
One page
report
Table 109: Additional Supported 12-Lead ECG Report Formats
Report Format Name Description One Page
or Multiple
Page Report
Computer Graphic
Record (CGR)
Shows three columns of four rows of medians at 25 mm/
s on the left side and three rows of waveforms printed at
12.5 mm/s on the right side (resulting in 10 seconds of
rhythm). The upper part of the report is text, such as the
measurements or interpretation. This results in a one page
report.
One page
report
288  MAC
™
5 A4/MAC
™
5 A5/MAC
™
5 Lite 5864335-001-1
