Report Formats
Item Name Description
8 Pace Annotations Displays pace annotaions for patients with a pacemaker. The pace
annotations represent pacemaker pulses.
Available only when HD Pace option is enabled. See Enable HD Pace on
page 67 for detailed information.
NOTE:
When two pace annotations are detected so close to each other
that they cannot be uniquely shown on the report, a single pace
flag with two flag tips is printed to indicate this condition.
9 Page Number Displays the page number of the ECG patient report in the format
page x of y, where x is the current page number and y is the total
number of pages.
10 Report Format Displays the configured report format title used to preview the ECG
patient report.
11 12SL Version Displays the 12SL version used to analyze the ECG patient report.
12 Product Model Displays the product model.
13 Filter Setting Displays the filter of the ECG waveform (measured in Hz), with Zero
Phase Distortion (ZPD for High Pass filter).
14 Gain Setting Displays the gain of the ECG waveform (measured in mm/mV).
15 Speed Setting Displays the speed of the ECG waveform (measured in mm/s).
16 Clinical Data Displays the clinical data gathered during the ECG test, such as:
• Technician ID
NOTE:
If the logged-in user has a Technician ID associated with their
user account, the Technician ID is automatically populated in
the preview. If the user modifies the value of the Technician
ID field in the Patient Information screen, the preview is
refreshed with the updated Technician ID.
• Test Indication
• Priority
• Visit Number
• Medical History
• List of Medications
Rhythm Report Format
Rhythm reports contain patient information, waveform data, and ECG acquisition
data. A rhythm report is a continuous recording of a patient's ECG in a digital format
5864335-001-1  MAC
™
5 A4/MAC
™
5 A5/MAC
™
5 Lite 291
