Configure Settings
Button Action
Test Connection Select this setting to test the particular destination is
available and online.
• If the connection is successful, a success message
displays and the Save button is enabled.
• If the connection fails due to an error, a failure
message displays. Troubleshoot the error and test the
connection.
NOTE:
This option only tests the destination is available
and online. It does not guarantee that the transmit
will succeed. At the time of actual connection or
transmission, it can fail, even if the test shows
Success.
Configure ECG
Select Settings > ECG menu to configure the following:
• ECG Acquisition - Configure ECG Acquisition on page 129
• Filter, Gain, and Speed - Configure Filters, Gain, and Speed on page 132
• 12SL Interpretations - Configure 12SL Interpretations on page 135
• Display Formats of ECG and Rhythm Leads - Configure Display Formats of ECG and
Rhythm Leads on page 137
• Patient Reports - Configure Patient Reports on page 140
• Lead Sets - Configure Lead Sets on page 145
• Rhythm - Configure Rhythm on page 148
• Critical Value Notifications - Configure Critical Value Notifications on page 149
• Full Disclosure - Configure Full Disclosure on page 151
Configure ECG Acquisition
1. Select Settings > ECG > Acquisition.
The Acquisition screen displays.
5864335-001-1  MAC
â„¢
5 A4/MAC
â„¢
5 A5/MAC
â„¢
5 Lite 129
