Record an ECG or Rhythm
2. After completing your tasks, select the Done icon to close the patient report.
A message displays asking you if you want to start a new patient test.
Select one of the options below:
• New Patient to start a test for a new patient, see Start a Test for a New
Patient on page 51. This action will clear the previous patient information.
• Continue with Same Patient to start a new test for the same patient. The live
waveform for this patient displays on the screen.
Full Disclosure Overview
The Full Disclosure ECG option shows one lead of the patient waveform for a
maximum of 5 minutes. From this waveform, you can create a Full Disclosure report
(FD Report) or create a 12-lead ECG. It starts after you connect a patient to the
acquisition module AND you are viewing the waveforms.
This feature may be helpful for clinicians that need to acquire an ECG on:
• A child that will not sit still or is anxious.
• A patient that is experiencing symptoms or stable arrythmias and would require a
12 lead ECG during those symptoms.
You can acquire a Full Disclosure ECG only if you purchase the Full Disclosure option,
and enable it in the Options Manager.
Automatic acquisition of ECG does not start while in the Full Disclosure tab.
5864335-001-1  MAC
â„¢
5 A4/MAC
â„¢
5 A5/MAC
â„¢
5 Lite 89
