Technical Specifications
Item Description
Pace Annotation Dedicated pace channel on display and printed reports
Pace digital sampling rate 75,000 samples/second per channel
Table 124: ECG Data Processing Specifications
Item Description
ECG Interpretation Marquette 12SL ECG Analysis Program for Adults and Pediatrics
Computerized measurements 12-lead analysis
Heart rate meter 30 to 300 beats per minute (BPM) with an accuracy of ±10% or 5
BPM, whichever is greater. Heart rates outside this range will not
display.
ECG data formats GE Hi-Fidelity ECG, XML
Pre-acquisition Provides 10 seconds of instantaneous ECG acquisition
Digital rhythm Up to 5 minutes of continuous rhythm storage (exportable as a
PDF)
Storage 300 records consisting of 10 second Resting ECG records and
Digital Rhythm records on the device internal memory
External storage USB-compliant flash drive supporting the FAT32 file system
Downsampled ECG waveform Bandwidth: 0.04 to 300 Hz
Sample rate: 2 ksps
Resolution: 1.22 µV
Analyzed ECG waveform Bandwidth: 0.04, 0.56 ZPD to 300 Hz
Sample rate: 500 and 1000 sps
Resolution: 4.88 µV
Additional report filters 20 Hz, 40 Hz, 100 Hz, 150 Hz or 300 Hz
Channels Up to 12 channels, skew between channels: < 100 μS
Environmental Specifications
Table 125: Environmental Specifications
Item Description
Operating Conditions
Temperature 10ºC to 40ºC (50° F to 104° F)
Relative Humidity (RH) 20% to 95% (non-condensing)
