Configure Settings
Field Action Description
12SL
Interpretation
Enable or disable
this setting.
Displays or hides the 12SL analysis in the ECG report.
Default value:
• Not applicable for 1 by 10s @25mm/s, 1 by 10s
@50mm/s and Expanded media 12ld formats.
• Disabled for all other formats.
Print Only if
Abnormal
Enable or disable
this setting.
If you enable this setting, an ECG report prints only if the
12SL analysis indicates that it is abnormal.
If you disable this setting, all ECG reports print.
Default value:
• Not applicable for 1 by 10s @25mm/s, 1 by 10s
@50mm/s and Expanded media 12ld formats.
• Disabled for all other formats.
7. Select Add.
A new row is added to the report configuration table.
8. Repeat steps 5 to 7 to add more report printing configurations.
9. To edit an existing report printing configuration:
a) To enable the edit mode, select anywhere in the row of the report printing
configuration that you want to modify.
b) Make changes to the configuration as per the information in Table 38:
Report Printing Settings on page 144.
c) Select Save.
10. To delete an existing report printing configuration:
a) Select the Delete icon for the report printing configuration you want to
delete.
NOTE:
You can delete only one report printing configuration at a time. To delete
more than one report printing configuration, repeat this step.
b) Select Save.
Configure Lead Sets
The device includes the default lead set configurations below:
