Technical Specifications
Item Description
Input current range A @100V to 625mA @240V
780 mA @100V AC to 110 mA @240V AC
Input frequency 50/60 Hz ± 3 Hz
Table 121: Battery Specifications
Item Description
Type Replaceable and rechargeable internal battery
Charge time Approximately 240 minutes from total discharge when device is off
(standby).
Battery capacity The system shall be able to acquire and print a single page 12-
lead Resting ECG report every fifteen minutes for a minimum
of three hours when the battery is installed and the battery is
fully charged (with five minutes auto standby enabled and all
accessories on except KISS), without AC connection.
Table 122: Other Input Device Specifications
Item Description
External USB barcode reader Fixed and variable length types
Symbologies: Code-128, PDF417, Code 39, Interleaved Code 2 of
5, and Data Matrix symbology for characters A-Z (upper case), a-z
(lower case), and 0-9 for all supported languages.
ECG Specifications
Table 123: ECG Data Acquisition Specifications
Item Description
Signal input Type CF, Defibrillation-Proof
Defibrillation protection: Per IEC 60601-2-25:2011
Dynamic range AC Differential ± 10mV, DC offset ± 600 mV
Common mode rejection >125 dB (>100 dB with AC filter disabled)
Input impedance >50 MΩ @ 10 Hz, defibrillator protected
Patient leakage current <10 µA
Detection of pacemaker pulse Duration: 0.2 ms to 2.1 ms
Amplitude: 2 mV to 700 mV
Separation: 1 ms or greater
5864335-001-1  MAC
â„¢
5 A4/MAC
â„¢
5 A5/MAC
â„¢
5 Lite 335
