Product Overview
Item Name Description
19 Preview ECG icon Select anywhere on the Full Disclosure ECG. The 10 seconds
of ECG data is selected.
Click Preview ECG.
A preview of the recorded 10 seconds of data for all leads
displays in the configured preview report format in the
maximize view. Select the minimize icon to view the report.
20 Select Lead icon Displays the default test type and display format. Select
anywhere around the ellipsis icon and select a different value.
You can only make a change before you record an ECG. You
can make a change before and during the recording of a
rhythm.
NOTE:
Any change to the test type and display format only
applies to the current patient. For a new patient, the
values are reset to the default settings.
21 Full Disclosure tab Displays a full disclosure ECG.
22 Home tab Displays the live waveform for the current patient connected
to the device.
User Menu Options Description
The User Menu is located at the top right corner of the Acquisition screen.
16  MAC
â„¢
5 A4/MAC
â„¢
5 A5/MAC
â„¢
5 Lite 5864335-001-1
