Product Overview
Item Name Description
11 Notification Area Displays messages:
• printing status and progress
• report transmission status
• Hookup Advisor lead quality status
The messages display one at a time in the sequence of
occurrence. The messages do not display when a patient
is connected and the hookup advisor is evaluating the
waveform.
12 Hookup Advisor Lead
Quality Status Indicator
Displays the lead quality status indicator in three circles that
change to yellow, red, or green, based on the lead quality.
13 Filter, Speed and Gain Displays the default waveform filter, speed, and gain. Select
anywhere around the ellipsis icon and select a different value.
You can only make a change before you record an ECG. You
can make a change before and during the recording of a
rhythm.
NOTE:
A change to the filter, speed or gain is applicable to the
current patient. For a new patient, the values are reset to
default settings.
14 Start Rhythm icon Select to print or digitally record the rhythm report.
15 Start ECG icon Select to record an ECG.
16 Lead Set and Display Format Displays the default test type and display format. Select
anywhere around the ellipsis icon and select a different value.
You can only make a change before you record an ECG. You
can make a change before and during the recording of a
rhythm.
NOTE:
Any change to the test type and display format only
applies to the current patient. For a new patient, the
values are reset to the default settings.
NOTE:
The items below display only after you purchase and enable Full Disclosure in the Settings
screen.
17 Restart icon Select to restart the Full Disclosure ECG.
A message displays as The full disclosure data will be cleared.
Do you want to proceed?
18 Full Disclosure Report icon Select to generate a Full Disclosure report.
The Full Disclosure report for the selected lead displays for
your review.
5864335-001-1  MAC
â„¢
5 A4/MAC
â„¢
5 A5/MAC
â„¢
5 Lite 15
