GE MAC 5 A4 User Manual

Report Formats
A
Report Formats
ECG Report Formats
Table 108: Supported 12-Lead ECG Report Formats
Report Format Name Description One Page
or Multiple
Page Report
1 by 10s @25mm/s Shows one column of 12 rows of waveforms. Each column
is 10 seconds wide and printed at 25 mm/s.
One page
report
1 by 10s @ 50 mm/s Shows one column of 12 rows of waveforms. Each column
is 10 seconds wide and printed at 50 mm/s. 5 seconds are
printed on each page. This results in a two page report.
Multiple
page report
2 by 5s @25mm/s Shows two columns of six rows of waveforms. Each column
is 5 seconds wide and printed at 25 mm/s.
One page
report
2 by 5s @ 50 mm/s Shows two columns of six rows of waveforms. Each column
is 5 seconds wide and printed at 50 mm/s. One column is
printed on each page. This results in a two page report.
Multiple
page report
2 by 5s + 1 Rhythm Ld Shows two parts:
• The upper part consists of two columns of six rows of
waveforms. Each column is 5 seconds wide and printed
at 25 mm/s.
• The lower part consists of one row of 10 seconds
of one lead. The rhythm lead shown in the report is
configurable.
One page
report
2 by 10s Shows two columns of six rows of waveforms. Each column
is 10 seconds wide and printed at 25 mm/s. One column is
printed on each page. This results in a two page report.
Multiple
page report
4 by 2.5s Shows four columns of three rows of waveforms. Each
column is 2.5 seconds wide and printed at 25 mm/s.
One page
report
5864335-001-1  MAC
™
5 A4/MAC
™
5 A5/MAC
™
5 Lite 287
