GE MAC 5 A4 User Manual

Configure Settings
Field Action Description
Simulated
Patient Data
Enable or disable
this setting.
If this setting is enabled, you can use simulation patient
data for demonstrations or troubleshooting.
The system generates and displays simulated ECG
waveforms on the Acquisition screen. The label at the
top of the screen indicates that the ECG waveform is
based on simulated data from the internal simulator,
and not actual patient data.
If this setting is disabled, the system displays
waveforms recorded from a patient attached to the
device.
Default value: Disabled
Auto-ECG Enable or disable
this setting.
If this setting is enabled, as soon as the ECG signal is
good, the device automatically starts recording 10-
seconds of ECG data for only one ECG per patient
connection.
Default value: Enabled
Print Preview
Auto Full
Screen
Enable or disable
this setting.
If this setting is enabled, the system automatically
displays the ECG preview window in full screen mode.
If this setting is disabled, the system displays the ECG
preview window in normal mode.
This setting is disabled, if the Print Preview Mode value
is configured to Never.
Default value: Enabled
3. Click Save.
Configure Filters, Gain, and Speed
1. Select Settings > ECG > Filters, Gain, Speed.
The Filters, Gain, Speed screen displays.
132  MAC
™
5 A4/MAC
™
5 A5/MAC
™
5 Lite 5864335-001-1
