GE MAC 5 A4 User Manual

Configure Settings
Field Action Description
Hookup
Advisor Level
Select a value
from the drop-
down list to
configure when
the Electrode
Placement Image
automatically
expands, in
case of leadwire
failures.
The Hookup Advisor indicator displays yellow or red
depending on the severity of the signal failure in a
leadwire.
• If you select Yellow, the Electrode Placement Image
automatically expands when the indicator is yellow
or red. When the signal turns green, the Electrode
Placement Image automatically collapses.
• If you select Red, the Electrode Placement Image
automatically expands when the indicator is red.
When the signal turns yellow or green, the Electrode
Placement Image automatically collapses.
• If you select Never, the Electrode Placement
Image does not automatically expand or collapse,
regardless of the type of signal received. You
can manually expand and collapse the Electrode
Placement Image at any time.
Default value: Never
Print Preview
Mode
Select a value
from the drop-
down list to
configure the
print preview
mode.
• If Always is selected, a preview of the ECG always
displays after ECG acquisition.
• If Yellow is selected, a preview of the ECG displays
after ECG acquisition, if the Hookup Advisor status
for the 10-seconds ECG acquired is Yellow or Red.
• If Red is selected, a preview of the ECG displays after
ECG acquisition, if the Hookup Advisor status for the
10-seconds ECG acquired is Red.
• If Never is selected, a preview of the ECG is never
display after ECG acquisition.
Default value: Always
Acquisition
Mode
Select a value
from the drop-
down list to
configure the
acquisition mode.
• If Pre-acquisition is selected, the system acquires
the latest/previous 10-seconds of data for analysis.
• If Post-acquisition is selected, the system displays
the acquisition progress until 10-seconds of ECG
data is acquired.
Default value: Pre-acquisition
Delay Rhythm
Printing
Enable or disable
this setting.
If this setting is disabled, rhythm printing occurs in real-
time.
If this setting is enabled, the system waits until 10-
seconds of rhythm data is acquired before starting
rhythm printing.
Default value: Disabled
5864335-001-1  MAC
™
5 A4/MAC
™
5 A5/MAC
™
5 Lite 131
