GE MAC 5 A4 User Manual

Report Formats
Item Description
6 Pace channel. Pace annotations display in this channel for patients with a pacemaker.
The pace annotations show pacemaker pulses.
Available only when HD Pace option is enabled. See Enable HD Pace on page 67 for
detailed information.
NOTE:
When 2 pacemaker pulses are sensed so near each other that they cannot be
uniquely shown on the report, a one pace spike with two flag tips is printed to show
this condition:
7 Page number of the report. The page number increments for each page of the rhythm
report.
For the digital rhythm report, the page number is shown as Page <x> of <y>.
For the printed rhythm report, the page number is shown as Page <x>.
8 The type of report format (rhythm report).
9 The product name.
10 The Filter of the ECG waveform (measured in Hz), indicated with ZPD (for High Pass
filter).
NOTE:
You can change the filter before or during the recording and/or printing of a
rhythm.
For the printed rhythm report, the printing stops and restarts at the newly selected
filter. A gap is shown on the printed rhythm report where the change occurred. Each
time the rhythm printing starts after a change in filter, a calibration pulse is added
for each lead that tells which filter on the printed rhythm.
For the digital rhythm report, the calibration pulse of the last filter selected during
recording is shown on the full report.
11 The Gain of the ECG waveform (measured in mm/mV).
NOTE:
You can change the gain before or during the recording and/or printing of a rhythm.
For the printed rhythm report, the printing stops and restarts at the newly selected
gain. A gap is shown on the printed rhythm report where the change occurred.
Each time the rhythm printing starts after a change in gain, a calibration pulse is
added for each lead that tells the gain on the printed rhythm.
For the digital rhythm report, the calibration pulse of the last gain selected during
recording is shown on the full report.
