Regulatory and Safety Information
Table 139: Label Descriptions on the Bottom of the Device
Item
Label
Description
5
Option Code and
MAC Addr
ess Label
The MAC device addr
ess of the device.
Use the option codes to set up the purchased options in your
system.
6
Country Specific
Label
Country registration information.
5864335-001-1

MAC
â„¢
5 A4/MAC
â„¢
5 A5/MAC
â„¢
5 Lite

357
356
358
