Patient Information
Item Field Description
2 PID# Shows the unique identification number of the patient (patient ID).
3 Gender Shows the patient gender.
4 DOB (Age) Shows the patient date of birth and age. If the Date of Birth field is
configured to be hidden on the Patient Information screen, only Age Shows
on the bar.
5 Chevron Select the chevron to collapse or expand the Patient Information banner.
If the chevron is in a down position, the Patient Information banner is
collapsed, and if it is in the upward position, the Patient Information
banner is expanded.
6 BPM Shows the real-time beats per minute (BPM). The heart rate updates
whenever the heart rate calculation algorithm reports a change in the heart
rate. The heart rate does not display if it drops below 30 bpm, increases
above 300 bpm, or the system is not getting ECG data. In cases where the
heart rate does not display, three asterisk symbols show instead of the
heart rate.
Select the Patient Information banner to expand it into a full screen view. Fields
configured by your administrator display in the Patient Information screen.
Table 12: Patient Information Screen
Item Field Description
1 Patient
Information
tab
Shows patient information, such as patient first name, last name, gender,
age, and other configured information.
