Record an ECG or Rhythm
Table 20: Rhythm Tab
Item Name Description
1 Patient Information
Banner
Displays patient information such as patient first name, last name,
gender, age, and so on. Select anywhere in the Patient Information
banner to edit patient information for the rhythm report.
2 Rhythm report Displays the rhythm report. If a rhythm report contains multiple
pages, press the left and right arrows on the screen to navigate
from one page to another. For more information on the rhythm
report format, see Rhythm Report Format on page 291.
3 Gain, Filter, and
Speed
To change the gain, filter, or speed of the waveform, select
anywhere around the ellipsis icon on the lower, right corner of the
Rhythm tab and select a new value from the expanded list. The
rhythm report is refreshed with the selected gain, filter, and speed.
4 Done icon Closes the rhythm report after completing your tasks. For more
information, see Close a Patient Report on page 88.
5 Delete icon Deletes the rhythm report. For more information, see Delete a
Patient Report on page 87.
5864335-001-1  MAC
â„¢
5 A4/MAC
â„¢
5 A5/MAC
â„¢
5 Lite 81
