Page #93 background image
Record an ECG or Rhythm
Item Name Description
2 Full Disclosure Report Displays the Full Disclosure report. If a Full Disclosure report
contains more than one pages, click the left and right arrows on the
screen to see the next page.
When you record Full Disclosure ECG:
• If the acquisition module is disconnected, the Full Disclosure
report displays empty space on the screen.
• If the lead is disconnected or the ECG waveform does not
display, the Full Disclosure report displays a straight horizontal
line on the screen, and transforms into square waves on the
printed or transmitted FD Report.
NOTE:
Only a FD Report or Rhythm Report can have a single tab. The
ECG report will always have a tab, but if you enable a Rhythm
tab and select a FD Report, the Rhythm tab will be replaced by
the FD tab.
3 Gain, Filter, and
Speed
To edit the gain, filter, or speed of the waveform in the report, do the
steps as follow:
• Click the ellipsis icon that is on the lower right of the FD Report
tab.
• Select a new value from the expanded list.
• The Full Disclosure report refreshes with the selected gain, filter,
and speed.
4 Done icon Closes the Full Disclosure report. For more information, see Close a
Patient Report on page 88.
5 Delete icon Deletes the Full Disclosure report. For more information, see Delete
a Patient Report on page 87.
6 Edit icon Edits the patient information for the Full Disclosure report. For more
information, see Edit Patient Information in a Patient Report on page
87.
7 Copy icon Prints a copy of the Full Disclosure report. For more information, see
Print a Patient Report on page 85.
8 Transmit icon Transmits the Full Disclosure report. For more information, see
Transmit a Patient Report to a Configured Destination on page 82.
To start a new Full Disclosure report for the same patient, click the Full Disclosure
tab to navigate to the Full Disclosure waveform and application, and restart the Full
Disclosure ECG. For more information, see Record a Full Disclosure ECG on page 90.
5864335-001-1  MAC
â„¢
5 A4/MAC
â„¢
5 A5/MAC
â„¢
5 Lite 93
