Functions and symbols of the AB22A
AB22A in Setup mode
118 A0534-30.0 HBM: public MGCplus
Information
The "Unit" selection field in the "Transducer" setup window can be edited by
double clicking with
. Then you can enter up to four characters (for
example min
-1
, with
-1
as a character that is placed on the key).
Edit fields
You can enter numbers or letters in the edit fields. In some edit fields you
can only enter numbers (for example a zero value) because it would not
make any sense to enter letters.
The selected field appears in reverse video. Confirm your entries with
.
In the example on the left you can see one edit field with no content and
another edit field with content.
An edit field together with content can be
S directly overwritten,
S partially edited
S or completely deleted with the delete key
.
Entering numbers and letters
The keys of the alphanumeric input field are assigned seven times each: 1
number, 3 upper-case letters and 3 lower-case letters. A number appears
the first time you press the key, with letters appearing after it is pressed
again.
To enter consecutive letters that are both on the same key, press the cursor
key between the letters
.
User:
0.000
Zero point:
