System
Recording series of tests
264 A0534-30.0 HBM: public MGCplus
Information
The 1253 LONG format contains status information in the least significant
byte. To access this status, you should check this byte first (!) Scale, since
this will cause the least significant byte to be lost due to division by 256.
The status byte is structured as follows:
S Bit 0: Limit value output 1 active if set
S Bit 1: Limit value output 2 active if set
S Bit 2: Limit value output 3 active if set
S Bit 3: Limit value output 4 active if set
S Bit 4: Overflow of Gross signal if set
S Bit 5: Overflow of Net signal if set
S Bit 6: Calibration counter error if set
S Bit 7: Amplifier settings that are changed during the measurement (for
example by remote control) if they are set
