117
Load Correction (Correcting Values to Match Reference Values)
Setting the DC bias
1
Touch the DC BIAS key.
2
Touch the ON key and enter the DC bias
value with the keys.
1
2
Settable range: 0 V to 2.5 V
If you make a mistake, touch the C key to
reenter the value.
3
Touch the EXIT key.
The dialog box will be closed.
When low Z high-precision mode (p. 55)
is enabled, the valid setting range will differ
(from 0 V to 1 V).
When DC is selected for the compensation frequency setting, the DC bias setting cannot be set.
Selecting the parameters to use as reference values
1
Touch the MODE key.
2
Select the parameter mode of the refer-
ence value to be set.
3
Touch the EXIT key.
The dialog box will be closed.
See "Parameters" (p. 40).
• When DC is selected for the correction frequency setting, DC measurement (Rdc) is selected automati-
cally and the parameter to use for the reference value setting cannot be set.
• If you change the parameter to use as the reference value, the settings of reference value 1 and reference
value 2 are cleared. (See "Setting reference values" (p. 118).)
5
Error Correction
