Configuration
3/07 UDC3500 Universal Digital Controller Product Manual 103
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
DIG IN1
DIG IN2
DIG IN3
DIG IN4
RELAY 1
RELAY 2
RELAY 3
RELAY 4
RELAY 5
GATE1OT
GATE2OT
GATE3OT
GATE4OT
GATE5OT
FIX ON
FIX OFF
DIGITAL INPUT 1
DIGITAL INPUT 2
DIGITAL INPUT 3
DIGITAL INPUT 4
RELAY 1
RELAY 2
RELAY 3
RELAY 4
RELAY 5
OUTPUT FROM GATE 1
OUTPUT FROM GATE 2
OUTPUT FROM GATE 3
OUTPUT FROM GATE 4
OUTPUT FROM GATE 5
ALWAYS A “1”
ALWAYS A “0”
MA MODE
LR SPL1
ADAPT 1
MA MOD2 *
LR SPL2 *
ADAPT 2 *
Manual or Auto mode – Loop 1
0 = Manual 1 = Automatic
Local or Remote Setpoint – Loop 1
0 = Local 1 = Remote
Disable or Enable Adaptive Tune – Loop 1
0 = Disable 1 = Enable
Manual or Auto Mode – Loop 2
0 = Manual 1 = Automatic
Local or Remote Setpoint – Loop 2
0 = Local 1 = Remote
Disable or Enable Adaptive Tune – Loop 2
0 = Disable 1 = Enable
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
L1 PV
L1 SP
CONST K
L2 PV *
L2 SP *
* These prompts appear
only when 2 Loops are
configured.
The following selections apply if the Gate Type is
B LT A (B less than A) or B GT A (B greater than A).
ANALOG INPUT 1
ANALOG INPUT 2
ANALOG INPUT 3
ANALOG INPUT 4
ANALOG INPUT 5
LOOP 1 PROCESS VARIABLE
LOOP 1 SETPOINT
K CONSTANT
LOOP 2 PROCESS VARIABLE
LOOP 2 SETPOINT
GATE(n) K
(n) = 1, 2, 3, 4, or 5
–999.0 to +9999
GATE (n) K CONSTANT—This selection only
appears if CONST K is configured for GATE(n)INA.
