Page #83 background image
Configuration
3/07 UDC3500 Universal Digital Controller Product Manual 67
3.8 SP Program 3 Set Up Group
Introduction
An optional third SetPoint Program. SP Programs #3 and #4 can be linked together to
form a single, longer SP Program.
ATTENTION
Please note that the configurations used in SP Program #1 for Program End,
Program State, Power Up and Key Reset affect all other SP Programs. For this
reason, Program #1 must always be enabled in order to enable Programs #2, 3
and/or 4.
Function Prompts
Table 3-8 SP PROG3 Group Function Prompts
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
SP PROG3
(optional feature)
SP Ramp must be
disabled for SP
Program prompts to
appear. If SP Rate is
enabled, it does not
operate while an SP
Program is running.
DISABLE
ENABLE
ENABLE2
ENABL12
SETPOINT RAMP/SOAK PROGRAM #3—Available
only with controllers that contain this option.
SP RAMP must be disabled.
DISABLE—Disables setpoint programming.
ENABLE—Enables setpoint programming–Loop 1.
ENABLE2—Enables setpoint programming–Loop 2.
ENABL12—Enables setpoint programming–Both
Loop1 and Loop 2.
STRT SEG
1 to 20
START SEGMENT NUMBER
END SEG
2 to 20 even numbers
Always end in a soak
segment
(2, 4, ... 20)
END SEGMENT NUMBER
ATTENTION When SP Programs 3 and 4 are
linked, this parameter does not appear. The value is
automatically set to 20 and the End Segment
Number is controlled by the selection for End
Segment in SP Program #4.
RAMPUNIT
TIME
EU/MIN
EU/HR
RAMPUNIT—Engineering Units for Ramp Segments
TIME in hours: minutes
RATE in Engineering units per minute
RATE in Engineering units per hour
RECYCLES
0 to 100 recycles
Number of Program Recycles
ATTENTION Not used when linking programs
HOTSTART
DISABLE
ENABLE
HOT START—This feature allows the SP Program
to start at the current PV value rather than the
current Setpoint value.
