Modbus Read, Write and Override Parameters plus Exception Codes
392 UDC3500 Universal Digital Controller Product Manual 3/07
10.7.9 Math
Table 10-18 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Math.
Table 10-18 Set-up Group – Math
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
8-Segment
Characterizer 1
198 00C6 198 INT R/W 0 = Disable
1 = Input 1
2 = Input 2
3 = Input 3
4 = Input 4
5 = Input 5
6 = Loop 1 – Output
7 = Loop 2 – Output
X0 Input to 8-
Segment
Characterizer 1
26 401A 16410 FP R/W 0.00 to 99.99 %
X1 Input-Char1 27 401B 16411 FP R/W 0.00 to 99.99 %
X2 Input-Char1 28 401C 16412 FP R/W 0.00 to 99.99 %
X3 Input-Char1 29 401D 16413 FP R/W 0.00 to 99.99 %
X4 Input-Char1 30 401E 16414 FP R/W 0.00 to 99.99 %
X5 Input-Char1 31 401F 16415 FP R/W 0.00 to 99.99 %
X6 Input-Char1 32 4020 16416 FP R/W 0.00 to 99.99 %
X7 Input-Char1 33 4021 16417 FP R/W 0.00 to 99.99 %
X8 Input-Char1 34 4022 16418 FP R/W 0.00 to 99.99 %
Y0 Output from 8-
Segment
Characterizer 1
35 4023 16419 FP R/W 0.00 to 99.99 %
Y1 Input-Char1 36 4024 16420 FP R/W 0.00 to 99.99 %
Y2 Input-Char1 37 4025 16421 FP R/W 0.00 to 99.99 %
Y3 Input-Char1 38 4026 16422 FP R/W 0.00 to 99.99 %
Y4 Input-Char1 39 4027 16423 FP R/W 0.00 to 99.99 %
Y5 Input-Char1 40 4028 16424 FP R/W 0.00 to 99.99 %
Y6 Input-Char1 41 4029 16425 FP R/W 0.00 to 99.99 %
Y7 Input-Char1 42 402A 16426 FP R/W 0.00 to 99.99 %
Y8 Input-Char1 43 402B 16427 FP R/W 0.00 to 99.99 %
