3.3 Configuration Procedure
Introduction
Each of the Set Up groups and their functions are pre-configured at the factory.
The factory settings are shown in Table 3-4 through Table 3-24. If you want to change
any of these selections or values, follow the procedure in Table 3-3. This procedure tells
you the keys to press to get to any Set Up group and any associated Function prom
pt.
Procedure
ATTENTION
The prompting scrolls at a rate of one group every 2/3 seconds when the SET UP or FUNC/LOOP 1/2 key
is held in. Also, or keys will move group prompts forward or backward twice as fast.
Table 3-3 Configuration Procedure
Step Operation Press Result
1
Enter Set Up Mode
Set Up Upper Display = SETUP
Lower Display = TUNING (This is the first Set Up Group title)
2
Select any Set Up
Group
Set Up
Sequentially displays the other Set Up group titles shown in the
prompt hierarchy in
Table 3-2 Configuration Prompt Hierarchy.
You can also use the or keys to scan the Set Up groups
in both directions. Stop at the Set Up group title that describes the
group of parameters you want to configure. Then proceed to the
next step.
3
Select a Function
Parameter
Func
Upper Display = the current value or selection for the first function
prompt of the selected Set Up group.
Lower Display = the first Function prompt within that Set Up group.
Sequentially displays the other function prompts of the Set Up
group you have selected. Stop at the function prompt that you want
to change, then proceed to the next step.
4
Change the Value
or Selection
or
Increments or decrements the value or selection that appears for
the selected function prompt. If you change the value or selection of
a parameter while in Set Up mode but then decide not to enter it,
press the Man/Auto key once. This will recall the original
configuration. This “recall” procedure does not work for a Field
Calibration process. Field Calibration is a one-way operation.
5
Enter the Value or
Selection
Func
Enters value or selection made into memory after another key is
pressed.
6
Exit Configuration
Lower
Display
Exits configuration mode and returns controller to the same state it
was in immediately preceding entry into the Set Up mode. It stores
any changes you have made.
If you do not press any keys for 30 seconds, the controller times out
and reverts to the mode and associated display used prior to entry
into Set Up mode.
