Installation
3/07 UDC3500 Universal Digital Controller Product Manual 13
Pre-installation Information
If the controller has not been removed from its shipping carton, inspect the carton for
damage then remove the controller.
• Inspect the unit for any obvious shipping damage and report any damage due to
transit to the carrier.
• Make sure a bag containing mounting hardware is included in the carton with the
controller.
• Check that the model number shown on the inside of the case agrees with what you
have ordered.
2.2 Condensed Specifications
Honeywell recommends that you review and adhere to the operating limits listed in Table
2-1 when you install your controller.
Table 2-1 Condensed Specifications
Specifications
Analog Inputs
Up to three Universal analog inputs. These can easily be configured to operate as 2
Universal and 2 High Level or as 1 Universal and 4 High Level inputs.
Accuracy:
± 0.10% of full scale typical (± 1 digit for display)
Can be field calibrated to ± 0.05% of full scale typical
16-bit resolution typical
Sampling Rate: All inputs are sampled six times per second
Temperature Stability: ± 0.0075% of Full Scale span / ˚C change—typical
Input Impedance:
0-20 and 4-20 Milliampere Inputs: 250 ohms
0-10 Volt and –1 to +1 Volt Input: 200K ohms
All Others: 10 megohms
Maximum Lead Wire Resistance:
Thermocouples: 50 ohms/leg
100 ohm, 200 ohm, 500 ohm and 1000 ohm RTD: 100 ohms/leg
100 ohm Low RTD: 10 ohms/leg
Slidewire Input for Position Proportional Control (Input 3 only):
100 ohm to 1000 ohm resistive slidewire types
Herculine
©
Models 10260 and 11280 Slidewire Emulation
Analog Input Signal
Failure Operation
Burnout Selections: Upscale, Downscale, Failsafe or None
Thermocouple Health: Good, Failing, Failure Imminent or Failed
Failsafe Output Level: Configurable 0-100% of Output range
Stray Rejection Common Mode
AC (50 or 60 Hz): 120 dB (with maximum source impedance of 100 ohms) or ± 1 LSB (least
significant bit) whichever is greater with line voltage applied.
DC: 120 dB (with maximum source impedance of 100 ohms) or a ±1 LSB whichever is
greater with 120 Vdc applied.
DC (to 1 KHz): 80 dB (with maximum source of impedance of 100 ohms) or ±1 LSB
whichever is greater with 50 Vac applied.
Normal Mode
AC (50 or 60 Hz): 60 dB (with 100 % span peak-to-peak maximum)
Digital Inputs (Four)
(Optional)
+30 Vdc source for external dry contacts or isolated solid-state contacts. Digital Inputs are
isolated from line power, earth ground, analog inputs and all outputs.
