Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 433
10.7.25 Clock
Table 10-34 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Clock.
Table 10-34 Set-up Group – Clock
Parameter
Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Clock Hours 16 4010 16400 FP R/W 0 to 23
Clock Minutes 17 4011 16401 FP R/W 0 to 59
Clock Seconds 18 4012 16402 FP R/W 0 to 59
Clock Month 137 4089 16521 INT R/W 0 = Unused
1 = January
2 = February
3 = March
4 = April
5 = May
6 = June
7 = July
8 = August
9 = September
10 = October
11 = November
12 = December
Clock Day 19 4013 16403 FP R/W 1 to 31
Clock Year 20 4014 16404 FP R/W 2005 to 2099
Time Zone (GMT) 21 4015 16405 FP R/W -1200 to +1300 (hours and
minutes away from GMT)
Note: The Time Zone setting is used only for Email purposes, it has no other function.
