3/07 UDC3500 Universal Digital Controller Product Manual 179

3.28 Read Maintenance Set Up Group

Introduction

The Read Maintenance group prompts are part of the Healthwatch feature. These prompts

let you view the values of the Healthwatch Timers and Counters. All of the values in this

Set Up Group are “Read Only” and cannot be changed.

Function Prompts

Table 3-28 READ MAINTENANCE Group Function Prompts

Function Prompt

Lower Display

Selections or

Range of Setting

Upper Display

Parameter

Definition

DAYS 1

0 to 9999 Shows elapsed time of Timer 1 in Days.

HRS.MIN1

00.00 to 23.59 Shows elapsed time of Timer 1 in Hours and

Minutes.

DAYS 2

0 to 9999 Shows elapsed time of Timer 2 in Days.

HRS.MIN2

00.00 to 23.59 Shows elapsed time of Timer 2 in Hours and

Minutes.

DAYS 3

0 to 9999 Shows elapsed time of Timer 3 in Days.

HRS.MIN3

00.00 to 23.59 Shows elapsed time of Timer 3 in Hours and

Minutes.

COUNTS 1

0-9999 (1 = 1000 counts

for output relays 1 to 5)

Shows the value of Counter 1.

COUNTS 2

Same as COUNTS 1 Shows the value of Counter 2.

COUNTS 3

Same as COUNTS 1 Shows the value of Counter 3.
