Page #425 background image
Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 409
10.7.16 Input 5
Table 10-25 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Input 5.
Table 10-25 Set-up Group – Input 5
Parameter
Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Input 5 Type 134 4086 16518 INT R/W 0 = Disable
1 = 0-20mA
2 = 4-20mA
3 = 0-5V
4 = 1-5V
ATTENTION
Changing the Input Type will result in the loss of Field Calibration values and will restore the
Factory Calibration values.
Input 5
Transmitter
Characterization
135 4087 16519 INT R/W 0 = B TC
1 = E TC H
2 = E TC L
3 = J TC H
4 = J TC M
5 = J TC L
6 = K TC H
7 = K TC M
8 = K TC L
9 = NNM H
10 = NNM L
11 = Nicrosil H TC
12 = Nicrosil L TC
13 = Plat H
14 = Plat L
15 = R TC
16 = S TC
17 = T TC H
18 = T TC L
19 = W TC H
20 = W TC L
21 = 100 PT RTD
22 = 100 PT LO RTD
23 = 200 PT RTD
24 = 500 PT RTD
25 = 1000PT
26 = Radiamatic RH
27 = Radiamatic RI
28 = Linear
29 = Square Root
Input 5 High
Range Value
82 0052 82 FP R/W –999. to 9999.
Engineering Units
