10.7.23 Time Event
Table 10-32 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Time Event.
Table 10-32 Set-up Group – Time Event
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Time Event 1 184 40B8 16568 INT R/W
0 = None
1 = Alarm 1 SP2
2 = Alarm 2 SP2
3 = Alarm 3 SP2
4 = Alarm 4 SP2
5 = STrSP/R
6 = Timer
7 = Auto
8 = MAN FS
9 = Use SP1
10 = Use SP2
Time Event 1
Calendar Type
185 40B9 16569 INT R/W
0 = 5 Day Week
1 = 7 Day Week
2 = Day of Week
3 = Calendar
Time Event 1
Hour
97 4061 16481 FP R/W
0 to 23
Time Event 1
Minutes
98 4062 16482 FP R/W 0 to 59
Time Event 1
Month
186 40BA 16570 INT R/W 0 = Unused
1 = January
2 = February
3 = March
4 = April
5 = May
6 = June
7 = July
8 = August
9 = September
10 = October
11 = November
12 = December
Time Event 1
Days
99 4063 16483 FP R/W 1 to 31
