3/07 UDC3500 Universal Digital Controller Product Manual 177
3.27 Display Set Up Group
Introduction
This group includes selections for Decimal place, Units of temperature, Language and
Power frequency.
Function Prompts
Table 3-27 DISPLAY Group Function Prompts
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
DECIMAL DECIMAL POINT LOCATION—This selection
determines where the decimal point appears in the
display.
NONE
ONE
TWO
THREE
NONE—No Decimal Place—fixed, no auto-ranging
ONE—One Place
TWO—Two Places
THREE—Three Places
ATTENTION Auto-ranging will occur for selections
of one, two or three decimal places. For example,
should the instrument be configured for two decimal
places and the PV exceeds 99.99, then the display
will change to a single decimal place so that values
of 100.0 and above can be shown.
DECIMAL2
NONE
ONE
TWO
THREE
DECIMAL POINT LOCATION FOR LOOP 2—This
selection determines where the decimal point
appears in the display for Loop 2.
NONE—No Decimal Place—fixed, no auto-ranging
ONE—One Place
TWO—Two Places
THREE—Three Places
ATTENTION Auto-ranging will occur for selections
of one, two, or three places.
TEMP UNIT TEMPERATURE UNITS FOR BOTH LOOPS—This
selection will affect the indication and operation.
DEG F
DEG F—Degrees Fahrenheit – Degrees F
Annunciator lighted
DEG C
DEG C—Degrees Centigrade – Degrees C
Annunciator lighted
NONE
NONE—No temperature annunciators lighted. Upper
and Lower Displays will show temperature in
Degrees Fahrenheit when inputs are configured for
Thermocouple or RTD types.
