Honeywell UDC3500 - Input 2; Table 10-22 Set-Up Group - Input 2

Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 403
10.7.13 Input 2
Table 10-22 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Input 2.
Table 10-22 Set-up Group – Input 2
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Input 2 Type 170 00AA 170 INT R/W
0 = Disable
1 = B TC
2 = E TC H
3 = E TC L
4 = J TC H
5 = J TC M
6 = J TC L
7 = K TC H
8 = K TC M
9 = K TC L
10 = NNM H
11 = NNM L
12 = Nicrosil H TC
13 = Nicrosil L TC
14 = Plat H
15 = Plat L
16 = R TC
17 = S TC
18 = T TC H
19 = T TC L
20 = W TC H
21 = W TC L
22 = 100 PT RTD
23 = 100 PT LO RTD
24 = 200 PT RTD
25 = 500 PT RTD
26 = 1000PT
27 = Radiamatic RH
28 = Radiamatic RI
29 = 0-20 mA
30 = 4-20 mA
31 = 0-10 mV
32 = 0-50 mV
33 = 0-100 mV
34 = 0-500mV
35 = -10-10mV
36 = 0-1V
37 = 0-5 Vdc
38 = 1-5 Vdc
39 = 0-10 Vdc
40 = -1-1V
41 = Unused
42 = Unused
43 = Unused
44 = Thermocouple
Differential
45 = Unused
46 = PR
