Honeywell UDC3500 User Manual

Configuration
180 UDC3500 Universal Digital Controller Product Manual 3/07
3.29 Time Events Set Up Group
Introduction
This group appears only when the Real Time Clock option is installed. These selections
allow the user to program the instrument to perform specific functions at the same time of
day five or seven days a week or on one specific date and time. Up to two independent
functions can be configured.
Function Prompts
Table 3-29 TIME EVT Group Function Prompts
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
EVENT 1 EVENT 1—The function performed by this event.
NONE
ALM1SP2
ALM2SP2
ALM3SP2
ALM4SP2
STrSP/R
TIMER
AUTO
MAN FS
USE SP1
USE SP2
NONE
ALARM 1 SETPOINT 2 (NOTE 1)
ALARM 2 SETPOINT 2 (NOTE 1)
ALARM 3 SETPOINT 2 (NOTE 1)
ALARM 4 SETPOINT 2 (NOTE 1)
START SETPOINT PROGRAM OR RAMP
TIMER (NOTE 6)
AUTOMATIC MODE (NOTE 2)
MANUAL MODE AT FAILSAFE OUTPUT (NOTE 2)
CONTROL TO LOCAL SETPOINT 1 (NOTE 2)
CONTROL TO LOCAL SETPOINT 2 (NOTE 2)
TIME 1 TIME 1—Time of first event.
5DAY WK
FIVE-DAY WEEK—The configured event will occur
at the same time Monday through Friday.
7DAY WK
SEVEN-DAY WEEK—The configured event will
occur at the same time Sunday through Saturday.
DAYofWK
SAME DAY EVERY WEEK—The configured event
will occur once a week at the configured time.
CALENDR
CALENDAR—The configured event will occur once
at a specific date and time.
HOUR 1
0 to 23
HOUR—24 Hour setting
MINUTE1
0 to 59
MINUTE—60 Minute setting
MONTH 1
JANUARY – DECEMBR
MONTH—Month of the Year (NOTE 3)
DAY 1
1 to 31
1 to 7
DAY—Day of Month or Week
When “CALENDR” is configured: Day of the month
(NOTE 5)
When “DAYofWK” is configured: Day of the week
(Sunday = 1, Saturday = 7)
(NOTE 4)
