Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 399
10.7.11 Output Algorithms
Table 10-20 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Output Algorithms.
Table 10-20 Set-up Group – Output Algorithms
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Output
Algorithm
160 00A0 160 INT R/W 0 = Time Simplex
1 = Current Simplex
2 = Three Position Step or
Position Proportioning
3 = Time Duplex
4 = Current Duplex
5 = Current/Time Duplex
6 = Time/Current Duplex
Relay Cycle
Time
Increments
190
00BE 190 INT R/W 0 = 1 second increments
1 = 1/3 second increments
Motor Time
for Positional
Proportional
75 004B 075 INT R/W 5 to 1800 seconds
Relay Output
Action
243 00F3 243 INT R/W 0 = 1 OFF 2 OFF
1 = 1 ON 2 OFF
2 = 1 OFF 2 ON
3 = 1 ON 2 ON
Current
Range for
Current
Duplex
153 0099 153 INT R/W 0 = Full (100%)
1 = Split (50%)
Output
Algorithm
Loop2
160 01A0 416 INT R/W 0 = Time Simplex
1 = Current Simplex
2 = None
3 = Not Used
4 = Current Duplex
5 = Current/Time
6 = Time/Current
7 = Time Duplex
Relay Output
Action Loop2
175 01AF 431 INT R/W 0 = 1 OFF 2 OFF
1 = 1 ON 2 OFF
2 = 1 OFF 2 ON
3 = 1 ON 2 ON
Current
Range for
Current
Duplex
Loop2
153 0199 409 INT R/W 0 = 100%
1 = 50%
