Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
398 UDC3500 Universal Digital Controller Product Manual 3/07
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Gate 5 InputA (B
LT A or B GT A)
179 40B3 16563 INT R/W Same as ID 171
Gate 5 InputB
(OR, NOR, AND,
NAND, X OR, X
NOR)
169 40A9 16553 INT R/W Same as ID 153
Gate 5 InputB (B
LT A or B GT A)
180 40B4 16564 INT R/W Same as ID 172
Logic Gate5 K
Constant
104 4068 16488 FP R/W –999.0 to +9999
Gate 1 Out 154 409A 16538 INT R/W 0 = Relay 1
1 = Relay 2
2 = Relay 3
3 = Relay 4
4 = Relay 5
5 = Any Gate
6 = MA Mode
7 = LR SPL1
8 = ADAPT 1
9 = Reset Totalizer
10 = MA Mode Loop 2
11 = LR SP Loop 2
12 = Adapt Loop 2
Gate 2 Out 158 409E 16542 INT R/W Same as ID 154
Gate 3 Out 162 40A2 16546 INT R/W Same as ID 154
Gate 4 Out 166 40A6 16550 INT R/W Same as ID 154
Gate 5 Out 170 40AA 16554 INT R/W Same as ID 154
