Installation
3/07 UDC3500 Universal Digital Controller Product Manual 37
L1
L2/N
4
5
7
8
9
28
29
30
31
32
33
34
35
36
6
Cool Relay Load
Load
Power
Supply
Heat Relay Load
Out Relay #1
N.O.
N.O.
Out Relay #2
1
Dual Electromechanical relays are rated at 2 Amps @120 Vac or 240 Vac or
30 Vdc. Customer should size fuses accordingly. Use Fast Blo fuses only.
1
Figure 2-18 Output #2 – Dual Relay Output for Time Duplex
See Table 2-6 and Table 2-7 for other information about output types.
L1/Hot
1
Dual Electromechanical relays are rated at 2 Amps @120 Vac or 240 Vac or
30 Vdc. Customer should size fuses accordingly. Use Fast Blo fuses only.
See Input 3 Wiring Diagram for Slidewire Connections.
2
L1
L2/N
4
5
7
8
9
28
29
30
31
32
33
34
35
36
6
Motor
Power
Supply
Close (CCW)
Open (CW)
L2/N
1
Out Relay #1
N.O.
N.O.
Out Relay #2
2
Motor
Figure 2-19 Output #2 – Dual Relay Output for Position Proportional or
Three Position Step Control
See Table 2-6 and Table 2-7 for other information about output types. See Figure 2-8 for
Slidewire connections.
