Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 367
10.7.4 Setpoint Program #2
Table 10-13 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Setpoint Program #2.
Table 10-13 Set-up Group – Setpoint Program #2
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Setpoint Program
#2
128 6080 24704 INT R/W 0 = Disabled
1 = Enable 1
2 = Enable 2
3 = Enable 12
4 = Link 1 and 2
Start Segment # 41 6029 24617 FP R/W 1 to 20
End Segment
#(Soak)
129 6081 24705 INT R/W 0 = Soak 2
1 = Soak 4
2 = Soak 6
3 = Soak 8
4 = Soak 10
5 = Soak 12
6 = Soak 14
7 = Soak 16
8 = Soak 18
9 = Soak 20
Engineering Units
or Ramp
Segments
130 6082 24706 INT R/W 0 = HRS:MIN
1 = EU/Minute
2 = EU/Hour
Program Recycles 42 602a 24618 FP R/W 0 to 100
PV Hotstart 131 6083 24707 INT R/W 0 = Disabled
1 = Enabled
Segment #1
Ramp Time
1 6001 24577 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #1
PID SET
141 608D 24717 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #2 Soak
Setpoint Value
2 6002 24578 FP R/W Within Setpoint Limits
Segment #2 Soak
Time
3 6003 24579 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##2
31 601F 24607 FP R/W 0 to 99.9 (0 = no soak)
