Modbus Read, Write and Override Parameters plus Exception Codes
368 UDC3500 Universal Digital Controller Product Manual 3/07
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #2
PID SET
142 608E 24718 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #3
Ramp Time
4 6004 24580 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #3
PID SET
143 608F 24719 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #4 Soak
Setpoint Value
5 6005 24581 FP R/W Within Setpoint Limits
Segment #4 Soak
Time
6 6006 24582 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##4
32 6020 24608 FP R/W 0 to 99.9 (0 = no soak)
Segment #4
PID SET
144 6090 24720 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #5
Ramp Time
7 6007 24583 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #5
PID SET
145 6091 24721 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #6 Soak
Setpoint Value
8 6008 24584 FP R/W Within Setpoint Limits
Segment #6 Soak
Time
9 6009 24585 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##6
33 6021 24609 FP R/W 0 to 99.9 (0 = no soak)
Segment #6
PID SET
146 6092 24722 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
