Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 361
10.7.3 SP Ramp/Rate/Program #1
Table 10-12 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Setpoint Ramp/Rate.
Table 10-12 Set-up Group – Setpoint Ramp/Rate/Program #1
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
SP Ramp 150 0196 406 INT R/W 0 = Disabled
1 = Enable 1
2 = Enable 2
3 = Enable 12
Single SP Ramp
Time
25 0019 25 FP R/W 0 to 255 (minutes)
Final Ramp SP
Value
26 001A 026 FP R/W PV Range in
Engineering Units
SP Rate 174 01AE 430 INT R/W 0 = Disabled
1 = Enable 1
2 = Enable 2
3 = Enable 12
Rate Up (EU/HR) 108 006C 108 FP R/W 0 to 9999
Rate Down
(EU/HR)
109 006D 109 FP R/W 0 to 9999
Rate Up (EU/HR)
Loop2
108 016C 364 FP R/W 0 to 9999
Rate Down
(EU/HR) Loop2
109 016D 365 FP R/W 0 to 9999
Setpoint Program
#1
178 01B2 434 INT R/W 0 = Disabled
1 = Enable 1
2 = Enable 2
3 = Enable 12
Start Segment # 88 0058 88 FP R/W 1 to 20
End Segment
#(Soak)
176 00B0 176 INT R/W 0 = Soak 2
1 = Soak 4
2 = Soak 6
3 = Soak 8
4 = Soak 10
5 = Soak 12
6 = Soak 14
7 = Soak 16
8 = Soak 18
9 = Soak 20
Engineering Units
or Ramp
Segments
182 00B6 182 INT R/W 0 = HRS:MIN
1 = EU/Minute
2 = EU/Hour
