Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
362 UDC3500 Universal Digital Controller Product Manual 3/07
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Program Recycles 89 0059 89 FP R/W 0 to 100
Controller Status
at Program End
180 00B4 180 INT R/W 0 = Last Setpoint and
Mode
1 = Manual, Failsafe
Output
Program End
State
181 00B5 181 INT R/W 0 = Disable SP
Program
1 = Hold at Program
End
Power UP 211 40D3 16595 INT R/W 0 = Abort
1 = Resume
2 = Restart
Reset SP
Program
(ToBEGIN)
179 00B3 179 INT R/W 0 = Disable
1 = Via Keypad
2 = Rerun
PV Hotstart 226 00E2 226 INT R/W 0 = Disabled
1 = Enabled
Segment #1
Ramp Time
57 0039 057 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #1
PID SET
191 40BF 16575 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #2 Soak
Setpoint Value
58 003A 058 FP R/W Within Setpoint Limits
Segment #2 Soak
Time
59 003B 059 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##2
87 4057 16471 FP R/W 0 to 99.9 (0 = no soak)
Segment #2
PID SET
192 40C0 16576 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #3
Ramp Time
60 003C 060 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #3
PID SET
193 40C1 16577 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
