Configuration
64 UDC3500 Universal Digital Controller Product Manual 3/07
3.7 SP Program 2 Set Up Group
Introduction
An optional second SetPoint Program. SP Programs #1 and #2 can be linked together to
form a single, longer SP Program.
ATTENTION
Please note that the configurations used in SP Program #1 for Program End,
Program State, Power Up and Key Reset affect all other SP Programs. For this
reason, Program #1 must always be enabled in order to enable Programs #2, 3
and/or 4.
Function Prompts
Table 3-7 SP PROG2 Group Function Prompts
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
SP PROG2
(optional feature)
SP Ramp must be
disabled for SP
Program prompts to
appear. If SP Rate is
enabled, it does not
operate while an SP
Program is running.
DISABLE
ENABLE
ENABLE2
ENABL12
LINK
SETPOINT RAMP/SOAK PROGRAM #2—Available
only with controllers that contain this option.
SP RAMP must be disabled.
DISABLE—Disables setpoint programming.
ENABLE—Enables setpoint programming–Loop 1.
ENABLE2—Enables setpoint programming–Loop 2.
ENABL12—Enables setpoint programming–Both
Loop1 and Loop 2.
LINK—Programs 1 and 2 are linked
STRT SEG
1 to 20
START SEGMENT NUMBER
ATTENTION When SP Programs 1 and 2 are
linked, this prompt does not appear and this value is
automatically set to 1
END SEG
2 to 20 even numbers
Always end in a soak
segment
(2, 4, ... 20)
END SEGMENT NUMBER
ATTENTION When linking Setpoint Programs 1
and 2, this End Segment Number determines the
end of the entire linked program.
RAMPUNIT
TIME
EU/MIN
EU/HR
RAMPUNIT—Engineering Units for Ramp Segments
TIME in hours: minutes
RATE in Engineering units per minute
RATE in Engineering units per hour
ATTENTION Normally the same as Program #1
when linking programs.
RECYCLES
0 to 100 recycles
Number of Program Recycles
