Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 379
10.7.6 Setpoint Program #4
Table 10-15 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Setpoint Program #4.
Table 10-15 Set-up Group – Setpoint Program #4
Parameter
Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Setpoint Program
#4
136 6088 24712 INT R/W 0 = Disabled
1 = Enable 1
2 = Enable 2
3 = Enable 12
4 = Link 3 and 4
Start Segment # 125 607D 24701 FP R/W 1 to 20
End Segment
#(Soak)
137 6089 24713 INT R/W 0 = Soak 2
1 = Soak 4
2 = Soak 6
3 = Soak 8
4 = Soak 10
5 = Soak 12
6 = Soak 14
7 = Soak 16
8 = Soak 18
9 = Soak 20
Engineering Units
or Ramp
Segments
138 608A 24714 INT R/W 0 = HRS:MIN
1 = EU/Minute
2 = EU/Hour
Program Recycles 126 607E 24702 FP R/W 0 to 100
PV Hotstart 139 608B 24715 INT R/W 0 = Disabled
1 = Enabled
Segment #1
Ramp Time
85 6055 24661 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #1
PID SET
181 60B5 24757 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #2 Soak
Setpoint Value
86 6056 24662 FP R/W Within Setpoint Limits
Segment #2 Soak
Time
87 6057 24663 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak #2
115 6073 24691 FP R/W 0 to 99.9 (0 = no soak)
