Modbus Read, Write and Override
Parameters plus Exception Codes
378
UDC3500 Universal Digital Controller Product Manual
3/07
Parameter
Register
Address
Data
Type
Access
Data Range or
Enumerated Selection
Description
ID
Hex
Decimal
Guaranteed
Soak #20
82
6052
24658
FP
R/W
0 to 99.9 (0 = no soak)
Segment #20
PID SET
180
60B4
24756
INT
R/W
0 = SET1
1 = SET2
2 = SET3
3 = SET4
393
395
