Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 373
10.7.5 Setpoint Program #3
Table 10-14 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Setpoint Program #3.
Table 10-14 Set-up Group – Setpoint Program #3
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Setpoint Program
#3
132 6084 24708 INT R/W 0 = Disabled
1 = Enable 1
2 = Enable 2
3 = Enable 12
Start Segment # 83 6053 24659 FP R/W 1 to 20
End Segment
#(Soak)
133 6085 24709 INT R/W 0 = Soak 2
1 = Soak 4
2 = Soak 6
3 = Soak 8
4 = Soak 10
5 = Soak 12
6 = Soak 14
7 = Soak 16
8 = Soak 18
9 = Soak 20
Engineering Units
or Ramp
Segments
134 6086 24710 INT R/W 0 = HRS:MIN
1 = EU/Minute
2 = EU/Hour
Program Recycles 84 6054 24660 FP R/W 0 to 100
PV Hotstart 135 6087 24711 INT R/W 0 = Disabled
1 = Enabled
Segment #1
Ramp Time
43 602B 24619 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #1
PID SET
161 60A1 24737 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #2 Soak
Setpoint Value
44 602C 24620 FP R/W Within Setpoint Limits
Segment #2 Soak
Time
45 602D 24621 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##2
73 6049 24649 FP R/W 0 to 99.9 (0 = no soak)
