Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
374 UDC3500 Universal Digital Controller Product Manual 3/07
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #2
PID SET
162 60A2 24738 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #3
Ramp Time
46 602E 24622 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #3
PID SET
163 60A3 24739 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #4 Soak
Setpoint Value
47 602F 24623 FP R/W Within Setpoint Limits
Segment #4 Soak
Time
48 6030 24624 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##4
74 604A 24650 FP R/W 0 to 99.9 (0 = no soak)
Segment #4
PID SET
164 60A4 24740 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #5
Ramp Time
49 6031 24625 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #5
PID SET
165 60A5 24741 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #6 Soak
Setpoint Value
50 6032 24626 FP R/W Within Setpoint Limits
Segment #6 Soak
Time
51 6033 24627 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##6
67 6043 24643 FP R/W 0 to 99.9 (0 = no soak)
Segment #6
PID SET
166 60A6 24742 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
